The Connection Machine CM-1/CM-2




CM-2a, DataVault, CM-2 and applications






CM-2 and DataVault mass storage device





CM-1
CM-1





CM-1
CM-1 and its processor boards




The final design, used for both the CM-1 and its faster successor, the CM-2, was a massive, 5 feet tall cube formed in turn of smaller cubes, representing the 12-dimensional hypercube structure of the network that connected the processors together.

This hard geometric object, black, the non-color of sheer, static mass, was transparent, filled with a soft,constantly changing cloud of lights from the processor chips, red, the color of life and energy. It was the archetype of an electronic brain, a living, thinking machine.




Images © Thinking Machines Corporation, 1986-1987. Photo: Steve Grohe.

Text: © Tamiko Thiel
